Boring Kubernetes: A Real Front Door with Traefik

In Boring Kubernetes I migrated 23 services from Docker Compose to a single-node K3s box, and ended the post with a smug list of things I didn't need. One of them was:

No fancy ingress (Traefik/Nginx) — Tailscale + NodePort is enough.

Six months later, I've retired every NodePort and put a Traefik ingress in front of every interactive app. This is the story of why "enough" stopped being enough, and how the fix turned out to be code that was already running on the cluster.

The itch: NodePort was fine, until it wasn't

The dual-access networking from last time worked. Tailscale Subnet Router for remote access via *.svc.cluster.local, NodePort for fast local streaming. But two annoyances compounded.

Annoyance 1: NodePort is ugly. Every service meant remembering a random high port:

http://192.168.1.100:30896  # Jellyfin — was it 896 or 968?
http://192.168.1.100:30453  # Navidrome
http://192.168.1.100:30500  # Kavita

No TLS, no names, no bookmarks that survive a service redeploy. Fine for a media app you open from a TV once. Miserable for a dashboard you open ten times a day.

Annoyance 2: chatty HTTP over the subnet router felt sluggish. The subnet router is great for what it is — raw TCP and low-volume admin access. But every packet to grafana.harus-infrastructure.svc.cluster.local took the router hop: client → Tailscale → subnet-router pod → CoreDNS → service. For a bulk postgres:5432 connection you never notice. For an interactive app firing dozens of little XHRs per page, that hop adds up into a spinny, laggy feel even on the same WiFi.

I wanted one thing: type grafana.h.azusachino.icu into any device on my tailnet, get a green padlock, and have it feel like localhost.

Anatomy of the slow path

Why did grafana.harus-infrastructure.svc.cluster.local feel sluggish when a raw ping to the node was ~2ms? Because both the name and the address it resolves to are virtual cluster objects that only exist inside the node — and the only way a tailnet device can reach them is by routing every packet through the single subnet-router pod.

Walk one dashboard click through the old path:

flowchart LR
  B["Browser<br/>(tailnet device)"]
  WG["WireGuard<br/>tunnel"]
  SRP["subnet-router pod<br/>single replica<br/>routes + SNATs 10.43/16<br/>into the cluster"]
  KP["kube-proxy<br/>ClusterIP → pod DNAT"]
  G["grafana pod<br/>10.42.x.y:3000"]
  CD["CoreDNS 10.43.0.10<br/>(also a ClusterIP)"]

  B -->|"① every request"| WG
  WG -->|"② dozens per page"| SRP
  SRP -->|"③ forward + SNAT"| KP
  KP --> G
  SRP -.->|"DNS crosses the router too"| CD
  G -.->|"response retraces every hop"| B

  classDef pain fill:#c0392b,stroke:#7b241c,stroke-width:2px,color:#fff;
  class SRP pain;

Three things conspire, and none of them show up in a ping:

1. The destination is a ClusterIP, not a host. grafana resolves to something like 10.43.x.y — a virtual IP that lives only in the node's iptables. To reach it from outside, the subnet router advertises 10.43.0.0/16 over Tailscale, so packets are tunneled to the subnet-router pod, which forwards and SNATs them into the cluster network. That pod is an extra L3 hop and a single replica: every byte to every cluster service funnels through one pod's network stack (even with TS_USERSPACE=false it's a separate netns doing subnet routing, not host networking).
2. DNS crosses the router too. The split-DNS rule sends *.cluster.local to CoreDNS at 10.43.0.10 — itself a ClusterIP behind the router. So even resolving the name pays the hop tax before the first data packet moves.
3. Interactive pages multiply it. A postgres:5432 bulk transfer opens one connection and streams — you never feel the hop. A Grafana page fires dozens of small, latency-sensitive requests, and each TCP + TLS handshake is several round-trips before the first byte. Multiply "one extra pod hop + SNAT + kube-proxy DNAT" across all of that and a dashboard that should feel instant has visible lag on every click.

The subnet router isn't broken — it's doing exactly what a router does. It's just the wrong tool for chatty, handshake-heavy HTTP. The fix is to stop making interactive traffic terminate at a virtual ClusterIP behind a forwarding pod.

The realization: the ingress controller was already there

Here's the embarrassing part. When I wrote "no ingress controller," I was wrong. The K3s-bundled Traefik had been running in kube-system the entire time — I'd just never given it a single route.

Correction to my past self: the cluster does have an ingress controller. The bundled Traefik was simply unused (zero routes).

That reframes the whole project. This wasn't "install and operate Traefik." It was "adopt something already running and exposed." No new Deployment, no Helm install, no operator. Just:

1. Teach DNS to point *.h.azusachino.icu at the node.
2. Give Traefik a trusted wildcard cert.
3. Drop an IngressRoute next to each service.

How it's wired: killing the router hop

K3s ships Traefik as a LoadBalancer Service, and ServiceLB (the svclb-traefik DaemonSet) binds host ports 80/443 directly on the node. My node's tailnet IP is 100.89.137.15 — a real tailnet peer, not a ClusterIP. So the data path now terminates on the node's own host networking:

flowchart LR
  B["Browser<br/>(tailnet device)"]
  WG["WireGuard<br/>tunnel"]
  TR["Traefik on the node<br/>host :443 (ServiceLB hostPort)<br/>keep-alive pool to backends"]
  KP["node-local iptables<br/>ClusterIP → pod DNAT"]
  G["grafana pod<br/>10.42.x.y:3000"]

  B -->|"request to 100.89.137.15:443"| WG
  WG -->|"one hop to a real host"| TR
  TR -->|"node-local, reused upstream"| KP
  KP --> G
  G -.->|"response"| B

  classDef good fill:#1e8449,stroke:#145a32,stroke-width:2px,color:#fff;
  class TR good;

Same request, but look at what's gone:

• The tunnel ends at a real host. 100.89.137.15:443 is the node itself on the tailnet — one WireGuard hop to a genuine peer, no forwarding pod in the middle. The subnet-router pod is entirely off the hot path.
• The last hop is node-local. From the host, reaching the backend is a single in-node iptables DNAT (ClusterIP → pod) — microseconds, no tunnel, no SNAT through a second netns.
• Traefik keeps connections warm. It holds a keep-alive pool to each backend, so the per-request handshake cost that hurt most over the router path largely disappears — the browser handshakes once with Traefik over TLS, and Traefik reuses hot upstreams.

The division of labor is now clean:

• Traefik handles all HTTP/L7 — every interactive web app. There's no raw HTTP over the tailnet anymore.
• Subnet router stays for DNS — CoreDNS's ClusterIP is still how *.h.azusachino.icu itself resolves — plus raw non-HTTP TCP like postgres:5432. Exactly the traffic that never minded the hop.
• NodePorts are retired entirely.

DNS: one wildcard to rule them all

I don't want a DNS record per service. I want *.h.azusachino.icu to land on the Traefik entrypoint, and let Traefik sort out routing by Host header.

Two pieces make that work. First, K3s CoreDNS auto-imports custom server blocks from a ConfigMap, so I template the whole subdomain to the node's tailnet IP:

# 01-infrastructure/traefik/coredns-custom.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: coredns-custom
  namespace: kube-system
data:
  h-azusachino.server: |
    h.azusachino.icu {
      template IN A {
        answer "{{ .Name }} 60 IN A 100.89.137.15"
      }
      template IN AAAA {
        rcode NOERROR
      }
    }

Second, a Tailscale split-DNS rule (set once in the console) routes h.azusachino.icu → 10.43.0.10, the CoreDNS ClusterIP. Now any tailnet device resolving grafana.h.azusachino.icu gets 100.89.137.15, hits Traefik, and Traefik matches the host.

Yes — that DNS lookup still crosses the subnet router to reach CoreDNS. The difference is it's a once-per-name, 60-second-cached cost, not a per-request one. The data path — the thousands of packets that interactive latency is actually made of — now goes straight to the host. That's the whole trade: keep the cheap thing on the router, move the expensive thing off it.

TLS: real Let's Encrypt certs for tailnet-only hosts

This is the part I'm most pleased with. These hosts are not publicly reachable — they only exist on my tailnet. Normally that rules out Let's Encrypt, because HTTP-01 validation needs a public IP.

DNS-01 doesn't. It proves domain ownership by writing a TXT record via the Cloudflare API, which never requires the host itself to be reachable from the internet. So I get genuine, browser-trusted wildcard certs for hosts that live entirely behind Tailscale. No mkcert, no per-device CA trust, no "your connection is not private" clickthroughs.

I don't deploy my own Traefik to configure this — I deep-merge onto the bundled chart with a HelmChartConfig, which K3s's helm-controller layers on top of the chart's managed values:

# 01-infrastructure/traefik/helmchartconfig.yaml
apiVersion: helm.cattle.io/v1
kind: HelmChartConfig
metadata:
  name: traefik
  namespace: kube-system
spec:
  valuesContent: |-
    persistence:
      enabled: true
      storageClass: local-path
      size: 128Mi
      path: /data
    # acme.json must be writable by the non-root traefik user (uid/gid 65532)
    podSecurityContext:
      fsGroup: 65532
      fsGroupChangePolicy: "OnRootMismatch"
    env:
      - name: CF_DNS_API_TOKEN
        valueFrom:
          secretKeyRef:
            name: traefik-cf-dns-token
            key: CF_DNS_API_TOKEN
    certificatesResolvers:
      le:
        acme:
          email: [email protected]
          storage: /data/acme.json
          dnsChallenge:
            provider: cloudflare
            resolvers: ["1.1.1.1:53", "8.8.8.8:53"]
    # Default cert for websecure: one LE wildcard, served by SNI to any route.
    tlsStore:
      default:
        defaultGeneratedCert:
          resolver: le
          domain:
            main: h.azusachino.icu
            sans: ["*.h.azusachino.icu"]

Three details worth calling out:

• acme.json on a local-path PVC. Let's Encrypt rate limits are unforgiving. Persist the cert store so a Traefik restart doesn't re-issue and burn your quota.
• fsGroup: 65532. Traefik runs as a non-root user; without the right group ownership it can't write acme.json and silently fails to persist certs.
• defaultGeneratedCert. One wildcard cert serves every route by SNI match. No per-route resolver config — a route just says tls: {} and inherits the padlock.

The Cloudflare token is a SealedSecret (traefik-cf-dns-token), scoped to Zone · DNS · Edit on the zone — the minimum DNS-01 needs.

Routing a service is now three lines of intent

With the plumbing done, adding a service is trivial. Drop an IngressRoute in the service's own directory (same namespace as its Service), listing both entrypoints and tls: {}:

# 01-infrastructure/grafana/ingressroute.yaml
apiVersion: traefik.io/v1alpha1
kind: IngressRoute
metadata:
  name: grafana
  namespace: harus-infrastructure
spec:
  entryPoints: [web, websecure]
  routes:
    - match: Host(`grafana.h.azusachino.icu`)
      kind: Rule
      services:
        - name: grafana
          port: 80
  tls: {} # inherits the LE wildcard *.h.azusachino.icu

Apply it, and you can test the route before DNS has propagated by faking the Host header:

curl -H "Host: grafana.h.azusachino.icu" http://100.89.137.15/

That's the entire per-service cost now. Two dozen apps — Grafana, Immich, Jellyfin, Vaultwarden, Karakeep, n8n — all follow the identical pattern, each host <name>.h.azusachino.icu. Public exposure stays a separate, deliberate concern: only the Cloudflare Tunnel allowlist is reachable off-tailnet.

The gotchas

• Version is chart-managed. The bundled Traefik tracks the K3s release (currently v3.6.x) and is not in my pinning discipline. A K3s upgrade can move it; I just record the observed version with a note rather than fighting it.
• Split-DNS is a manual console step. The coredns-custom half is in Git, but the Tailscale h.azusachino.icu → 10.43.0.10 rule lives in the Tailscale admin console. Easy to forget when rebuilding.
• DNS-01 needs the token in the right namespace. The SealedSecret must land in kube-system (where Traefik runs), not the app namespace.

Was it worth undoing my past self?

The old post's thesis was "boring is good — build it once, let it run." Adopting Traefik didn't betray that; it extended it. I didn't add a moving part — I lit up one that was already there and idle. The result is fewer things to remember, not more:

• ✅ Every app at a real name: <service>.h.azusachino.icu
• ✅ Green-padlock TLS everywhere, zero per-device trust, zero public exposure
• ✅ Interactive apps off the subnet-router data path — no more spinny dashboards
• ✅ NodePort port-roulette retired
• ✅ New service = one IngressRoute with tls: {}

The subnet router didn't go away — and its most load-bearing job now is the one that's easiest to miss: DNS. Even the shiny Traefik path can't resolve *.h.azusachino.icu without it, because those names answer at CoreDNS's ClusterIP, reachable only through the router. Beyond that it still carries raw, non-HTTP TCP (postgres:5432 and friends) from the tailnet. What it stopped carrying is interactive HTTP — that's all Traefik now. It just stopped being the tool for everything. That's the real lesson of a boring homelab: it's not that you never change it. It's that when you do, you reach for the thing already on the cluster before you install a new one.

What's next

Traefik closed the ingress gap. Poking at the cluster afterward, the honest list of what's still missing is short — and, keeping with the boring rule, each item either lights up something already adoptable or plugs into a tool I already run (Grafana, Prometheus, the Git → ArgoCD loop). No new control planes.

Roughly in order of leverage:

1. Alerting — Alertmanager → ntfy/Discord. I have all these metrics and still no way to be told when Immich OOMs or a PVC fills. Highest-return single addition.
2. Logs — Loki + Grafana Alloy. The missing observability pillar. Grafana already runs, so Loki is just a datasource: click a metric spike, jump to the correlated logs. (Alloy, not the now-deprecated Promtail.)
3. Automated updates — Renovate. I run GitOps but still bump image tags by hand — the "update anxiety" from the first post, still not fully dead. Renovate opens PRs, ArgoCD syncs. This finally closes that loop.
4. External uptime — Gatus. Prometheus scrapes internals; it won't tell me a route returns 502 from the outside. Declarative YAML, so it fits the GitOps repo.

And the one deliberate fork off the "boring" path, filed under someday, for the learning, not because it hurts: going multi-node HA (three servers for real etcd quorum — two is worse than one) with Longhorn replacing local-path so storage survives a node dying. That one breaks the single-node thesis this whole series is built on, so it stays firmly at the bottom.

The full tiered version — with a dataflow diagram of where each piece plugs in — lives as a living ROADMAP.md in the cluster repo, so the plan is versioned next to the manifests instead of trapped in a blog post.

---

TL;DR: Retired NodePorts and put the K3s-bundled Traefik (previously running with zero routes) in front of every HTTP app. Wildcard DNS via coredns-custom + Tailscale split-DNS, real Let's Encrypt certs for tailnet-only hosts via Cloudflare DNS-01, one default wildcard cert inherited by every route with tls: {}. No subnet-router hop, no port-roulette, green padlocks everywhere. Adopting beats installing.
